24EKOZD-12V-1PH
Product Details
⚙️ Rehlko 24EKOZD-12V-1PH – Key Specifications
- Model: 24EKOZD-12V-1PH
- Power Output: 24 kW (24 kVA) @ 60 Hz
- Voltage: 120V / 120/240V, Single Phase
- Frequency: 60 Hz
- Fuel Type: Diesel
- Engine Type: Rehlko Diesel Engine
- Engine Speed: 1800 RPM
- Cooling System: Closed-loop with heat exchanger
- Alternator Type: 4-pole, rotating-field
- Voltage Regulation: ±1.0%
- Insulation Class: H
- Control Panel: Decision-Maker® 3500 Controller
- Display: 12x2 LCD alpha-numeric
- Remote Start: 12-pin connector
- Communication Protocols: SAE J1939, SmartCraft™, NMEA 2000
- Sound Shield: Optional
📐 Dimensions & Weight
| Configuration | Length (mm/in) | Width (mm/in) | Height (mm/in) | Dry Weight (kg/lb) | Wet Weight (kg/lb) |
|---|---|---|---|---|---|
| Without Sound Shield | 1138 / 44.80 | 577.5 / 22.74 | 694 / 27.31 | 431 / 950 | 449 / 990 |
| With Sound Shield | 1197 / 47.12 | 652.5 / 25.69 | 711 / 27.99 | 471 / 1038 | 489 / 1078 |
