⚙️ Rehlko 21EKOZD-12V-1PH – Key Specifications

• Model: 21EKOZD-12V-1PH
• Power Output: 21 kW (21 kVA) @ 60 Hz
• Voltage: 120V / 120/240V, Single Phase
• Frequency: 60 Hz
• Fuel Type: Diesel
• Engine Type: 3-cylinder, 4-cycle
• Engine Speed: 1800 RPM
• Cooling System: Closed-loop with heat exchanger
• Alternator Type: 4-pole, rotating-field
• Voltage Regulation: ±1.0%
• Insulation Class: H
• Control Panel: Decision-Maker® 3500 Controller
• Display: 12x2 LCD alpha-numeric
• Remote Start: 12-pin connector
• Communication Protocols: SAE J1939, SmartCraft™, NMEA 2000
• Sound Shield: Optional
• Dimensions (Approx.):
  • Length: 1121 mm (44.13 in.)
  • Width: 577.5 mm (22.74 in.)
  • Height: 694 mm (27.31 in.)
  • Length w/ Sound Shield: 1197 mm (47.12 in.)
  • Width w/ Sound Shield: 652.5 mm (25.69 in.)
  • Height w/ Sound Shield: 711 mm (27.99 in.)
• Dry Weight: 422 kg (930 lbs)
• Wet Weight: 440 kg (970 lbs)
• Dry Weight w/ Sound Shield: 462 kg (1019 lbs)
• Wet Weight w/ Sound Shield: 480 kg (1059 lbs)
• Certifications: EPA Tier III Marine Auxiliary
