21EKOZD-12V-1PH
Product Details
⚙️ Rehlko 21EKOZD-12V-1PH – Key Specifications
- Model: 21EKOZD-12V-1PH
- Power Output: 21 kW (21 kVA) @ 60 Hz
- Voltage: 120V / 120/240V, Single Phase
- Frequency: 60 Hz
- Fuel Type: Diesel
- Engine Type: 3-cylinder, 4-cycle
- Engine Speed: 1800 RPM
- Cooling System: Closed-loop with heat exchanger
- Alternator Type: 4-pole, rotating-field
- Voltage Regulation: ±1.0%
- Insulation Class: H
- Control Panel: Decision-Maker® 3500 Controller
- Display: 12x2 LCD alpha-numeric
- Remote Start: 12-pin connector
- Communication Protocols: SAE J1939, SmartCraft™, NMEA 2000
- Sound Shield: Optional
- Dimensions (Approx.):
- Length: 1121 mm (44.13 in.)
- Width: 577.5 mm (22.74 in.)
- Height: 694 mm (27.31 in.)
- Length w/ Sound Shield: 1197 mm (47.12 in.)
- Width w/ Sound Shield: 652.5 mm (25.69 in.)
- Height w/ Sound Shield: 711 mm (27.99 in.)
- Dry Weight: 422 kg (930 lbs)
- Wet Weight: 440 kg (970 lbs)
- Dry Weight w/ Sound Shield: 462 kg (1019 lbs)
- Wet Weight w/ Sound Shield: 480 kg (1059 lbs)
- Certifications: EPA Tier III Marine Auxiliary
