🛥️ Tohatsu MFS5DDL – Key Specifications
Reliable, electric-start, and long-shaft ready—perfect for small boats, inflatables, and auxiliary power with added convenience and reach.
Model
Tohatsu MFS5DDL
Engine Type
Single-cylinder, 4-stroke
Digital CD ignition for fast, reliable starts
Thermostatically controlled water cooling system
Power Output
5 HP (3.68 kW)
Full throttle range: 4,500–5,500 RPM
Displacement
123 cc
Bore x Stroke
59 mm x 45 mm
Fuel System
Carbureted
Lubrication
Wet sump
Starting System
Electric start + manual recoil backup
Steering
360° full pivot steering for easy maneuverability
Trim & Tilt
Manual trim and tilt
Shaft Length
Long shaft – 20 inches (DDL = long shaft with electric start)
Dry Weight
Approx. 27 kg (59.5 lbs)
Fuel Tank
Built-in 1.0-liter tank
External fuel tank connection available
Noise & Emissions
EPA & CARB 3-Star rated for ultra-low emissions
Quiet operation with reduced induction noise
Convenience Features
Front-mounted shift lever
Ergonomic carrying handle
Oil level sight gauge
Twist-grip throttle control
Vibration absorption system
3-position storage without oil leakage
